Diesel Compression Gauge Test Kit AM-8030
- Checks diesel engine compression under cranking conditions
- Small profile¸ quick coupling adapters: for speed and security
- Flexible hose (355 mm) gives access to restricted plug and injector ports
- Dual scale 80 mm diameter Gauge 0 - 1000 Lb/In and 0 - 70 bar
- Kit comes complete with adapters for both direct and indirect diesel injected cars engine
- Built-in pressure relief valve: enables repeat tests without dismantling
- Dual scale 80 mm diameter Gauge 0 - 1000 Lb/In and 0 - 70 bar
- 80mm Dial 1000 PSI¸ 70 bar Gauge Assembly with hand grip protective rubber boot
- Stanadyne Dummy 112mm (length) x 19mm (Diameter)
- Dummy DL Injector 114mm (Length) x 21mm (Diameter)
- Glowplug Adapter- 114.4mm Length with M10 x 1.25 Thread
- Glowplug Adapter- 119mm Length with M10 x 1.0 Thread
- Glowplug Adapter- 73.5mm Length with M10 x 1.25 Thread
- Glowplug Adapter- 54mm Length with M12 x 1.25 Thread
- Glowplug Adapter- 72mm Length With 14mm x 1.50 Thread
- Dummy Injector M20 - 78mm Length with M20 x 1.25 Thread
- Dummy Injector M24 - 64mm Length with M24 x 2.0 Thread
- Clamp Plate 63.5mm ¸ 25mm wide¸ 17mm hole diameter
- Replacement Seal & Washer Set
- 90 degree elbow
- Formed fitted plastic case
- Heat shielded¸ reinforced hose
This is a high-quality aftermarket product.
